▎Product Introduction ：
The NA1100P-W Wired Active SF₆ Density Sensor provides high-precision monitoring of SF₆ gas density, pressure and temperature in high-voltage equipment chambers, featuring precision pressure/temperature measurement units with temperature compensation for exceptional accuracy, stability and interference resistance, while transmitting real-time data for trend analysis and alarm functions to ensure equipment safety and meet smart substation requirements for State Grid and Southern Power Grid.
▎Key Features ：
1.Optional wired/wireless configurations for real-time SF₆ density/pressure/temperature monitoring.
2.Real-time data transmission to monitoring center with trend analysis.
3.Strong EMI resistance with wide temperature compensation.
4.Complies with State Grid 'Smart Substation Technical Specifications Part 4: Digital Meters'.
5.Meets Southern Power Grid 'Digital Substation Remote Transmission Meter Technical Requirements'.
▎Technical Specifications ：
Parameter |
Value |
Model |
NA1100P-W |
Communication |
LoRa wireless |
Pressure Range |
(-0.1~0.9) MPa |
Density Error |
≤±0.5% F.S |
Temperature Range |
(-40~+70)°C |
Temperature Error |
±1°C |
Density Accuracy |
Class 1.0/1.6 @20°C, Class 1.6/2.5 @-40°C~+60°C (optional) |
Sealing Performance |
1×10⁻⁹ Pa·m³/s (helium leak test) |
Interface Size |
M20×1.5, G1/2 (customizable) |
Insulation Performance |
Insulation Resistance:≥100 MΩ Dielectric Strength:2 kV, 1 min, no breakdown |
Transmission Distance |
(300~500) m (extendable with repeater) |
Battery Life |
5 years |
